12 13
1
PREFACE
Screw the adapter ring in the direction of the
arrow to mount it on the camera.
3
To prevent the lens cap from appearing in the
shot when you take pictures, attach the lens cap
to the strap.
Fit and remove the lens cap by squeezing the
left and right sides of the cap.
1
Attaching the Lens Cap
Mounting the adapter ring on the camera
protects the lens and allows you to attach the
optional conversion lens. The adapter ring
should be mounted on the camera at all times to
protect the lens.
2
◆
Conversion Lens Guide
◆
Changes the focal length by a factor of 0.79 ×
(wide-angle: equivalent to 30 mm) without altering
the F-stop value of the lens.
h Wide conversion lens specifications
Magnification : 0.79 ×
Lens configuration : 3 lenses in 3 groups
Shooting range
: Approx. 10 cm to infinity
Dimensions : 32 mm (1.26 in.) × 70 mm
(2.76 in.) dia.
Mass (Weight) : Approx. 185 g (6.5 oz.)
Accessories : Adapter Ring AR-FX9 (see
below for specifications),
Lens caps (front and rear),
Lens pouch
●
! The enclosed adapter ring (for FinePix 4800/
6900/S602) cannot be used.
●
! Only use the wide conversion lens at the wide-
angle zoom setting.
● ! The flash cannot be used when the wide
conversion lens is mounted.
Wide Conversion Lens WL-FX9
Changes the focal length by a factor of 1.5x
(telephoto: equivalent to 340 mm) without altering
the F-stop value of the lens.
h Teleconversion lens specifications
Magnification : 1.5 ×
Lens configuration : 3 lenses in 3 groups
Shooting range
: Approx. 2.4 m to infinity
Dimensions : 55 mm (2.17 in.) × 65 mm
(2.56 in.) dia.
Mass (Weight) : Approx. 100 g (3.5 oz.)
Accessories : Adapter Ring AR-FX9 (see
below for specifications),
Lens caps (front and rear),
Lens pouch
●
! Only use the tele conversion lens at the telephoto
zoom setting.
●
! The flash cannot be
used when the
teleconversion lens
is mounted.
Teleconversion Lens TL-FX9
Conversion
lens
●
! Commercially available filters can be mounted on the lens when the adapter ring is attached, but no more than
one filter should be mounted at a time.
