FujiFilm FinePix 3800 - Manual (Page 52)

103
7
102
1. Switch the camera off.
2. Unplug the special USB cable from the
camera.
Macintosh
✽When you drag the icon to the Trash, “ ≠ ”
appears on the camera’s screen.
Drag the “Removable drive” icon on the desktop
to the Trash.
Digital
(USB) socket
Camera
DC IN 5V
socket
3 3. The menu option shown below appears.
Click on this option.
✽ Screen for Windows Me
4. The “Eject hardware” dialog box appears.
Click the [OK] button or the close button.
1
1. Quit all applications (FinePixViewer etc.)
that are using the camera.
2. Check that the indicator lamp is lit green
or that the self timer lamp is off (no data is
being exchanged with the computer).
Perform the steps shown below before you
switch the camera off. This procedure
differs depending on the operating system
software (or PC) you are using.
No PC operation is needed.
2. Left-click the Eject icon in the taskbar and
eject “USB Disk”.
✽Even when “Copying” is no longer displayed on the
computer, the camera and the computer may still be
exchanging data. Always check that the indicator
lamp is lit green or that the self timer lamp is off.
Windows 98 or 98 SE
Windows Me/2000 Professional/XP
2
For a DSC connection, proceed to step .
For a PC CAM connection, proceed to step .
3
2
1. Right-click the
removable disk icon in
the “My Computer”
window and select
Eject. This step is only
required in Windows
Me.
✽ Screen for Windows Me
7.4 Disconnecting the Camera
