5.2 Client S ide Nodes
Section Title
Nodes
Column Title Function
Legal Values
Node_Name Provide name for node Up to 32 alphanumeric characters
Node_ID OPTO22 device address. 0-255
Protocol Specify protocol used Optomux
Port Specify which port the device is connected to the FieldServer P1-P8 (with convertor), R1-R2 1
Example
// Client Side Nodes
Nodes
Node_Name , Node_ID , Protocol , Port
Optomux1 , 1 , Optomux , R1
5.3 Client S ide Map Descriptors
5.3.1 FieldServer Related Map Descriptor Parameters
Column Title Function Legal Values
Map_Descriptor_Name Name of this Map Descriptor
Up to 32 alphanumeric
characters
Data_Array_Name
Name of Data Array where data is to be stored / retrieved
in the FieldServer.
The use of this array is dependent on the Optomux
command used in the Map Descriptor.
For example some commands use one data value for all
module positions to be affected by the command (Driver
will only use one Data Array element). Other commands
may use one data element per module position specified. In
this case the FieldServer may use up to 16 Data Array
elements.
One of the Data Array
names from Section 4.
Data_Array_Offset Starting location in Data Array
O to
(Data_Array_Length-1)
Function Function of Client Map Descriptor Rdbc, Wrbc, Wrbx
1 Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction manual for details of the ports available
on specific hardware.
