5 CONFIGURING THE FIEL DSERVER AS AN OPTOMUX DRIVER CLIENT
For a detailed discussion on FieldServer configuration, please refer to the FieldServer Configuration Manual. The
information that follows describes how to expand upon the factory defaults provided in the configuration files
included with the FieldServer (See “.csv” files on the driver diskette).
This section documents and describes the parameters necessary for configuring the FieldServer to communicate
with an Optomux Device.
The configuration file tells the FieldServer about its interfaces, and the routing of data required. In order to enable
the FieldServer for Optomux Driver communications, the driver independent FieldServer buffers need to be
declared in the “Data Arrays” section, the destination device addresses need to be declared in the “Client Side
Nodes” section, and the data required from the servers needs to be mapped in the “Client Side Map Descriptors”
section. Details on how to do this can be found below.
Note that in the tables, * indicates an optional parameter, with the bold legal value being the default.
5.1 Client S ide Connection Parameters
Section Title
Connections
Column Title
Function Legal Values
Port
Specify which port the device is
connected to the FieldServer R1-R2, (FS-X40 Series)
R1 (FS-X20 Series)
Baud* Specify baud rate
Standard baud Rates in the range 300-38400. (Vendor
Limitation), 9600
Parity* Specify parity Even, Odd, None, Mark, Space
Data_Bits* Specify data bits 7, 8
Stop_Bits* Specify stop bits 1 (Vendor Limitation)
Protocol Specify protocol used Optomux
Poll Delay* Time between internal polls 0-32000 seconds, 1 second
Example
// Client Side Connections
Connections
Port , Baud , Parity , Protocol , Poll_Delay
R1 , 9600 , None ,Opto22 , 0.100s
