Battery Installation
• Place the Power Wheels ® Type H
battery upright in the battery
compartment. Do not remove the
battery from its protective foam
pocket. Make sure the battery
connector extends toward the
rear of the vehicle.
• Make sure a Power Wheels 25
amp fuse in good condition is
installed in the battery.
• Loosen the bolt in the seat with a
Phillips screwdriver.
• Remove the bolt and set it aside
for re-assembly of the seat.
• Push firmly on one of the back
fenders while pulling up on the
same side of the back of the seat
to release the tab on the seat
from the slot in the vehicle body.
• Repeat this procedure on the
other side of the seat.
• Lift the seat to remove it from the
vehicle body.
20
Important Note: Use only a Power Wheels ® Type H (4 Amp/hr.) battery with a Power Wheels ® 25 amp fuse installed.
Use of any other battery or fuse will damage your vehicle. Make sure that you charge the battery for at least 18
hours using the enclosed Power Wheels Type H 6 Volt charger before operating your vehicle for the first time.
Charge the battery for at least 18 hours after each use of the vehicle. Never charge the battery longer than 30
hours. Failure to follow these instructions may damage your battery and will void your warranty.
Battery
2
1
H
Push Here
Push Here
