• Insert the wire connector on the
main wire harness through the
large opening in the center of the
vehicle body.
• Plug the main wire harness
connector and the handlebar
wire harness connector together.
Assembly
16
Main Wire
Harness
Connector
Opening
Handlebar Wire
Harness
Connector
15
• Position the vehicle body upright.
• Fit the front tabs on the grille into
the slots in the front of the vehicle
body .
• Press firmly to snap the front tabs
into the slots.
• Press firmly on the middle of the
grille to snap the middle tabs into
the slots
.
• Press firmly near the back of the
grille to snap the back tabs into
the slots
. 3
2
1
Grille
Front
Tabs
Middle
Tabs
Back Tabs
Slots
16
1
2
3
