Fisher-Price BARBIE 76980 - Manual (Page 14)

Assembly
14
Steering
Column
Steering Column
Bushing
Vehicle
Body
Rectangular
Opening
• Insert the curved end of the steer-
ing column through the rectan-
gular opening in the vehicle
body.
• Rotate the steering column
bushing 1 /
4
turn and fit it into the
rectangular opening in the vehi-
cle body.
11
Steering
Column
Steering
Linkage
Hole
Guides
• Turn the vehicle body on its side.
• Insert the curved end of the steer-
ing column into the hole in the
steering linkage. Make sure the
steering column is positioned
between the guides on the
underside of the vehicle body.
12
Steering
Column
Steering Column
Bushing
• Wipe the steering column with a
paper towel to remove any dirt
or oils.
• Fit the steering column bushing
onto the straight end of the
steering column.
10
