Assembly
Do Not Omit Any Steps.
• Apply label #2 to the recessed
circle on each front wheel, as
shown.
F
2
• Turn the front wheels over.
• Fit a wheel bushing into the
rectangular opening in each
front wheel.
Wheel Bushing
2
1
Please Note: If the axle/linkage
assembly has detached from the
vehicle body during shipment,
please fit it back onto the fork on
the front of the vehicle body. Make
sure the center axle is toward the
rear of the vehicle.
• Turn the vehicle body upside
down.
• Fit a washer onto one end of the
front axle.
• Slide the front wheel, bushing side
first, onto the front axle.
Front
Wheel
Front
Axle
Washer
Wheel Bushing
3
Fork
Axle/Linkage
Assembly
Center Axle
Vehicle
Body
Vehicle
Body
11
