Assembly
30
Tabs
Tab
Left Headlight Lens
• Using safety scissors, remove the
headlight lenses from the plastic
connector. Dispose of the plastic
connector.
• Align the tabs on the back of the
right and left headlight lenses
with the slots in the grille.
Please Note: The right and left
headlight lenses are NOT inter-
changeable.
• Press firmly to snap the headlight
lenses into the grille.
TM
• Face the front of the vehicle.
• Insert the two tabs at the top of
the grille into the slots in the front
of the vehicle body.
• Press firmly to snap the tabs into
the slots.
• Fit the two side tabs on the grille
into the grille openings in the front
of the vehicle body.
• Press firmly at the bottom of the
grille to snap the two tabs at the
bottom of the grille into the vehi-
cle body.
31
Right Headlight Lens
Grille
Tabs
Grille
Grille Opening
Side Tab
Grille Opening
Slots
23
