Assembly
15
12
Please Note: The seat can be
assembled in either of two positions
for your child’s comfort.
• Push down on the center of the
seat and slide it toward the rear
of the vehicle.
• Align the screw holes in the back
of the seat with the first or second
set of holes in the vehicle body.
• Check your child’s fit in the
vehicle by observing foot to
pedal distance and adjust the
position of the seat, if necessary.
• Insert two #8 x 1" screws through
the holes in the back of the seat
and into the holes in the vehicle
body, as shown.
• Insert two screws through the
holes in the armrests and into the
vehicle body, as shown.
• Tighten the screws with a Phillips
screwdriver. Do not over-tighten.
#8 x 1" Screw – 4
Shown Actual Size
First
Position
Second
Position
• Insert the two tabs on the bottom
of the seat into the slots in the
vehicle body.
11
Tabs
Slots
Seat
Push
Here
