FujiFilm FinePix A120 - Manual (Page 6)

10 11
Getting
Ready
1
LOADING THE BATTERIES AND THE MEDIA
2 Load the batteries correctly as indicated by the
polarity icons.
1 Check that the camera is turned off (viewfinder
lamp is off) before opening the battery cover.
● ! Opening the battery cover while the camera is on, the camera
is turned off.
● ! Do not apply force to the battery cover.
Do not open the battery cover while the camera is
on. This could damage the xD-Picture Card or ruin
the image files on the xD-Picture Card.
Compatible batteries
h AA-size alkaline batteries (2) or AA-size Ni-MH batteries (sold separately) (2).
● ! Please use the same brand and grade AA-size alkaline batteries as those supplied with the camera.
◆
How to use the batteries
◆
h Never use the following types of batteries, as this could cause serious
problems such as batteries fluid leakage or overheating:
1. Batteries with split or peeling outer casings
2. Combinations of different types of batteries or new and used batteries
together
h Do not use manganese or Ni-Cd batteries.
h Soil, such as fingermarks on the poles of the batteries can shorten time for which the batteries can be
used.
h The time for which AA-size alkaline batteries (referred to hereafter simply as alkaline batteries) can be
used varies depending on the brand, and some alkaline batteries may stop providing power more
quickly than those supplied with the camera. Note also that due to their nature, the time for which
alkaline batteries can be used decreases in cold conditions (0°C to +10°C/+32°F to +50°F). The use of
AA-size Ni-MH batteries is better for this reason.
h Use Fujifilm Battery charger (sold separately) to charge AA-size Ni-MH batteries.
h See P.70, 71 for other notes on using batteries.
h When first purchased or if left unused for a long period, the time for which AA-size Ni-MH
batteries can be used may be shorter. See P.71 more information.
h When the surfaces of AA-size Ni-MH batteries terminals have become worn through repeated use or
the battery has been taken out of the camera and left for a long period, the battery may stop
supplying power or may become usable only for shorter periods.
To restore normal battery operation, open and close the battery cover several times to dislodge any
soiling on the terminals.
Outer casing
3
Indicator
Align the indicators on the xD-Picture Card slot and
xD-Picture Card and then push the card firmly all
the way into the slot.
● ! If the xD-Picture Card is oriented incorrectly, it will not go all
the way into the slot. Do not apply force when inserting an
xD-Picture Card.
LR6 AA-size
alkaline
batteries
● ! The information above is a guide for Photography mode. Depending on the camera mode and the type of batteries
used, the transition from “
C ” to “ V ” may occur more quickly.
● ! Due to the nature of the battery, the battery low warning may appear early when the camera is used in cold
locations. This is normal. Try warming the batteries in your pocket or a similar location before use.
✽ Battery level warning
1) The camera’s estimation of the remaining battery charge varies greatly depending on the camera operation mode.
Consequently, even if “ C ” or “ V ” is not displayed in Playback mode, one of them may appear when you change
to Photography mode.
2) Depending on the battery type and the level of charge in the batteries, the camera may run out of power without first
displaying a battery level warning. This is particularly to happen when batteries that have run out of charge once are
re-used.
In situation 2), immediately load new or fully charged replacement batteries.
Turn the camera on and check the battery charge.
4 Close the battery cover.
◆
How to replace the xD-Picture Card
◆
Pull out the xD-Picture Card, taking care that the
batteries do not fall out.
● ! If the xD-Picture Card is difficult to remove, take out the
batteries first.
Checking the battery charge
“C” appears as a small icon on the right-hand
side of the LCD monitor. “V” appears as a large
icon on the LCD monitor.
Lit red
Blinking red
1 There is ample battery charge.
2 There is insufficient charge left in the batteries.
The batteries will soon run out. Have a new set
of batteries ready.
3 The batteries are depleted. The display will
shortly go blank and the camera will stop
working. Replace or recharge the batteries.
Blinking red
Lit red
1
2
3
No icon
1
Getting Ready
◆
Power save function
◆
When this function is active, it turns off the LCD monitor to reduce power consumption if the camera is
not used for 30 seconds (
➡P.47). If the camera is then left unused for 2 or 5 minutes, the Power save
function turns the camera off. To restore power to the camera to take pictures, briefly close and then
reopen the lens cover. To play back images, close the lens cover then hold down the “Playback” button
for approx. 1 second.
