4.3. Client Side Node Descriptors
Section Title
Nodes
Column Title Function Legal Values
Node_Name Provide name for Node
Up to 32
alphanumeric
characters
Node_ID*
Identifies Node; needed only if Node Online/Offline
monitoring is used.
1-255
Protocol Specify protocol used SNMP
Adapter Specify network adapter N1, N2
2
IP_Address
IP Address of remote Agent. Refer to Appendix A.1
for more information.
Legal 4 byte IP
address on the
same subnet.
MIB_Style
Controls how MIB file is formatted. Refer to
Appendix A.3 for more info.
‘Standard’;
‘Custom’;
‘NuDesign’
MIB_Style_for_Traps
Controls how traps are reported in MIB file. Refer to
Appendix A.3 for more info. Style1; Style2;
Style3
Do_not_MIB_this_Node
Controls whether a Node’s traps contribute to the
MIB file. Where duplicate traps are sent to more
than one Node, second and subsequent Nodes will
not contribute to the MIB file. Review the example
MIB files and configuration file in Appendix A.3.
0 – Node’s traps contribute to MIB File.
1 – Node’s traps do not contribute to MIB file.
0; 1
SNMP_Read_Method*
If this parameter is set it is possible for the
FieldServer to sequentially read (walk) the SNMP
Server in the same way as the snmpwalk parameter
works on SNMP.
Walk, -
Example
// Client Side Nodes
Nodes
Node_Name, Node_ID, Protocol, Adapter, IP_Address, SNMP_Read_Method
Agent 1, 1, SNMP, N1, 192.168.1.174, Walk
