FS-8704-09 SNMP Driver Manual Page 22 of 39
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 9042 Toll Free: (888) 509 1970 email: [email protected]
Appendix A.3. MIB File Generation for the SNMP Server/Agent
It is necessary to create an updated MIB file corresponding to the available Data Arrays and Traps
configured in the Server configuration (*.csv) file. To create this MIB file, run the mb8sim.exe utility
supplied with the FieldServer in a DOS command window as follows:
•
mb8sim –cmy_config.csv
where my_config.csv is the newly created configuration file.
• hit ‘Q’ to quit. The program will have created a file called FServer.MIB, which may be compiled
into the SNMP Management application of choice.
When the MIB File is created the driver prints a message to the Error log.
The “MIB_Style” parameter specified in Section 4.3 provides three options for creating the MIB file.
•
Standard - this is the same as omitting the parameter
• NuDesign the MIB file produced is suitable for compilation by the NuDesign Browser.
• Custom - the file MIBhead.ini is used in preparing the MIB file.
Adapters
Adapter, Protocol, MIB_Style
N1, SNMP, Standard
NuDesign
Custom
