FS-8704-09 SNMP Driver Manual Page 7 of 39
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 9042 Toll Free: (888) 509 1970 email: [email protected]
4.2. Client Side Connection Descriptors
Section Title
Adapter
Column Title Function Legal Values
Adapter Adapter Name N1, N2 2
Protocol Specify protocol used SNMP
Length_Encode_Method
If this parameter is omitted or set to 0 the short form of
encoding length will be used. If the parameter is set to
1 (and the Length is ≤ 127) the long form of encoding
length will be used. For Length >127 short form will
be used regardless of the setting.
Long form: an extra byte will be inserted to indicate
the number of following bytes which indicates the
length of the following section in message.
Short form: only length value will be inserted.
0 (default),
1
SNMP_Community*
This parameter can be configured if it is required that
“Community” be a different name in order to receive
traps. Any string up to
255 characters,
Public
Example
// Client Side Connections
Adapters
Adapter, Protocol, Length_Encode_Method
N1, SNMP, 1
2
Not all ports shown are necessarily supported by the hardware. Consult the appropriate Instruction
manual for details of the ports available on specific hardware.
