3. Hardware Connections
The FieldServer is connected to the Ethernet using the UTP cable supplied. Two typical hardware
configurations are shown below:
1. FieldServer as SNMP Agent (Server)
2. FieldServer as SNMP Client
3.1. Hardware Connection Tips / Hints
The FieldServer utility program Ruinet will connect to the FieldServer even if the Netmask setting on
the PC differs from the setting on the FieldServer. SNMP will only work between Nodes for which
these settings correspond, however, thus all Nodes required to communicate using SNMP must have
the same Netmask setting.
