APPENDIX
A-3
KEY BEEP ( ON, OFF)
LANGUAGE ( ENGLISH, OTHERS)
RANGE UNIT
(nm, kt; km, km/h; sm, mph; nm&yd, kt; nm&m, kt; km&m, km/h; sm&yd, mph)
TEMPERATURE UNIT ( ° F, ° C)
DEPTH UNIT (m, ft, fa, pb)
TEMPERATURE SOURCE ( ETR, NMEA)
DEPTH SOURCE ( ETR, NMEA)
RESET TRIP LOG (YES, NO)
SPEED SOURCE (ETR, NMEA)
LAT/LON DISPLAY (DD ° MM. MM', DD ° MM. MMM', DD ° MM. MMMM',
DD
°
MM' SS.S")
TD DISPLAY ( LORAN C, DECCA)
SPEED DISPLAY ( SOG, STW)
POSITION DISPLAY ( LAT/LON, TD)
TIME DISPLAY (12 HOURS, 24 HOURS)
INFRARED REMOTE MODE ( A, B, C, D)
RANGE & BEARING MODE
(GREAT CIRCLE, RHUMB LINE)
BEARING READOUT (TRUE, MAGNETIC)
MAGNETIC VARIATION (MANUAL, AUTO 07.0
°
W)
DAISPLAY MODE ( DAY, NIGHT)*
GENERAL
SETUP
NAV
SOURCE
SETTINGS
NAV
OPTION
SYSTEM
CONFIGURATION
POSITION SOURCE
(FURUNO BB GPS, GP, LC, ALL)
SPEED AVERAGING (0-9999 seconds,
60 seconds)
LOCAL TIME OFFSET (-13:30-+13:30 hr, 00:00)
TEMP CALIBRATION (-40
°
F - +40
°
F, 0
°
F)
DEPTH CALIBRATION (-15 - +90 ft, 0 ft)
Page 1
Page 2
* = GD-1700 only.
3
4
GPS
SENSOR
SETTINGS
TD SETUP
LOCAL TIME OFFSET (-13:30-+13:30, 00:00)
GEODETIC DATUM ( WGS-84, WGS-72, OTHERS: See page A-9)
POSITION SMOOTHING (0 - 999 seconds, 000 seconds)
SPD/CSE SMOOTHING (0 - 999 seconds, 005 seconds)
GPS SPEED AVERAGE (0 - 999 seconds, 60 seconds)
LATITUDE OFFSET (0 - 9.999íN(S), 0.000'N)
LONGITUDE OFFSET (0 - 9.999'E(W), 0.000'E)
DISABLE SATELLITE (Max. 3)
LATITUDE ( 45 ° 35.000'N)
LONGITUDE ( 125
°
00.00'W)
ANTENNA HEIGHT (0 - 999 m, 5 m)
GPS FIX MODE ( 2D/3D, 3D)
COLD START (YES, NO)
GRI ( 9940: 11-27 (US west coast))
CORRECTION 1 (-999.9-+999.9
µ
s, 000.0
µ
s)
CORRECTION 2 (-999.9-+999.9 µ s, 000.0 µ s)
CHAIN ( 01: R-G (South Baltic))
CORRECTION 1 (-99.99-+99.99 µ s, 00.00 lane )
CORRECTION 2 (-99.99-+99.99
µ
s, 00.00 lane )
GPS STATUS soft key
(Displays status of GPS satellites.)
