2-1
2. WIRING
2.1 Wiring Overview
PROCESSOR UNIT
: Fabrication required
100-115V/220-230 VAC
1
φ, 50/60Hz
TB801
TB802
MONITOR UNIT
CONTROL UNIT
(RCU-014 or RCU-015)
RW-9600
15/30/40/50 m
(Max.100 m)
DPYC-2.5
DPYC-2.5
XH10P-W-6P L=1.5/10/20/30m
100-230 VAC
1 φ, 50/60 Hz
DVI-D/D SINGLELINK 5/10m
CONTROL UNIT
(RCU-016)
MEMORY CARD
INTERFACE
CU-200-FAR
F4
F3
F2
F1
ANTENNA UNIT
110 VAC, 3 φ,
60 Hz
220 VAC, 3
φ,
50 Hz
440 VAC, 3
φ,
50 Hz
200 VAC, 3 φ, 50 Hz
220 VAC, 3 φ, 60 Hz
POWER
SUPPLY
UNIT
RU-6522
RU-5693
RU-5466-1
TPYCY-2.5
XH10P-W-5P
L=10/20/30 m
TPYC-2.5
TPYC-1.5
TPYCY-1.5
440 VAC,
1
φ, 50/60 Hz
100-115 VAC/220-230V,
1
φ, 50/60 Hz
RU-1803
DPYC-2.5
100/110/115/
220/230 VAC
1
φ, 50/60 Hz
24 VDC
RU-3423
