C141-E112-01EN 5 - 31
Table 5.5 Information to be read by IDENTIFY DEVICE command (3 of 6)
* 1 Word 0: General configuration
Bit 15: 0 = ATA device 0
Bit 14-8: Vendor specific
Bit 7: 1 = Removable media device 0
Bit 6: 1 = not removable controller and/or device 1
Bit 5-1: Vendor specific
Bit 0: Reserved 0
*2 Number of Cylinders, *3 Number of Heads,
*11 Total number of user addressable sectors (LBA mode only.)
MPF3102AH MPF3153AH MPF3204AH
*2 X‘3FFF’
*3 X‘10’
*11 X‘01316AF0’ X‘01CA1E70’ X‘0262D5E0’
*4 Word 10-19: Serial number; ASCII code (20 characters, right-justified)
*5 Word 23-26: Firmware revision; ASCII code (8 characters, Left-justified)
*6 Word 27-46: Model number;
ASCII code (40 characters, Left-justified), remainder filled with blank code (X'20')
One of the following model numbers;
Fujitsu MPG3102AH
Fujitsu MPG3153AH
Fujitsu MPG3204AH
*7 Word 49: Capabilities
Bit 15-14: Reserved
Bit 13: Standby timer value 0 = Standby timer values shall be managed by the device
Bit 12: Reserved
Bit 11: IORDY support 1=Supported
Bit 10: IORDY inhibition 0=Disable inhibition
Bit 9: LBA support 1=Supported
Bit 8: DMA support 1=Supported
Bit 7-0: Vendor specific
*8 Word 51: PIO data transfer mode
Bit 15-8: PIO data transfer mode X'02'=PIO mode 2
Bit 7-0: Vendor specific
*9 Word 53: Enable/disable setting of word 54-58, 64-70 and 88
Bit 15-3: Reserved
Bit 2: Enable/disable setting of word 88 1=Enable
Bit 1: Enable/disable setting of word 64-70 1=Enable
Bit 0: Enable/disable setting of word 54-58 1=Enable
*10 Word 59: Transfer sector count currently set by READ/WRITE MULTIPLE command
Bit 15-9: Reserved
Bit 8: Multiple sector transfer 1=Enable
Bit 7-0: Transfer sector count currently set by READ/WRITE MULTIPLE without
interrupt supports 2, 4, 8 and 16 sectors.
