C141-E112-01EN 1 - 5
Model Formatted Capacity No. of Cylinder No. of Heads No. of Sectors
MPG3102AH 10,248 MB 16,383 16 63
MPG3153AH 15,371 MB 16,383 16 63
MPG3204AH 20,496 MB 16,383 16 63
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers.
Table 1.2 Model names and product numbers
Model Name
Capacity
(user area)
Mounting
Screw
Order No. Remarks
MPG3102AH 10.24 GB No. 6-32UNC CA05762-B321 —
MPG3153AH 15.37 GB No. 6-32UNC CA05762-B331 —
MPG3204AH 20.49 GB No. 6-32UNC CA05762-B341 —
1.3 Power Requirements
(1) Input Voltage
•
+ 5 V ±5 %
•
+ 12 V ±8 %
(2) Ripple
+12 V +5 V
Maximum 200 mV (peak to peak) 100 mV (peak to peak)
Frequency DC to 1 MHz DC to 1 MHz
