(2) LBA mode
Logical address assignment in the LBA mode starts from physical cylinder 0, physical head 0, and
physical sector 1. The logical address is advanced at the subsequent sector from the last sector of
the current track. The first physical sector of the subsequent physical track is the consecutive
logical sector from the last sector of the current physical track.
Figure 6.6 shows an example of (assuming there is no track skew).
LBA
2
LBA
1
LBA
607
LBA
606
LBA
605
606 605
LBA
604
LBA
0
3 2 1
Physical sector
ex: Zone 0
Physical parameter
- Physical sector: 1 to 592 (For the rest, 2 spare sectors)
Physical cylinder 0
Physical head 0 . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
LBA
1215
LBA
1214
LBA
1213
LBA
1212
3 2 1
Physical cylinder 0
Physical head 1 . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
LBA
610
LBA
609
LBA
608
608 607
606 605 608 607
Figure 6.6 Address translation (example in LBA mode)
6.3 Power Save
The host can change the power consumption state of the device by issuing a power command to
the device.
6.3.1 Power save mode
There are four types of power consumption state of the device including active mode where all
circuits are active.
In the power save mode, power supplying to the part of the circuit is turned off. There are three
types of power save modes:
•
Idle mode
•
Standby mode
•
Sleep mode
