23
For private channels mode
10. While pressing the CHANNEL knob, press the CH-16 key to
select private channel mode.
P01/CH:001
PRIV No.SELECT:[<][>]key
Figure 29
11. Press the arrow keys to select private channel (P01 to P20) to set.
P02/CH:---<-- ---- ---->
PRIV No.SELECT:[<][>]key
Figure 30
12. Press the ENT key.
P02/CH:001
ENABLE=TX[1] RX[2] UN [3]
Figure 31
13. Rotate the CHANNEL knob to select a channel.
P02/CH:234
ENABLE=TX[1] RX[2] UN [3]
Figure 32
14. Select telecom mode; 1 for simplex or 2 for duplex.
P02/CH:234
TELECOM= SIMP [1] DUP[2]
Figure 33
15. Select communication mode; 1 for simplex, or 2 for duplex.
P02/CH:234
TX POWER=HIGH[1] LOW [2]
Figure 34
16. Select TX power; 1 for high output power, or 2 for low output
power.
17. To set other private channels, repeat steps 11 to 16.
