Page 31: Water temp sender
Page 28
Air Temp Sender
Paddlewheel Sender
White (Sender Signal)
Black & Shield (Ground)
6
5
4
3
2
1
7
8
9
10
11
12
1
2
3
6
5
4
MG2000 Speedometer
Harness HN0587
Speedometer Cable
1 2 3 4 5 6 7 8 9 10 11 12
12- pin connector
Pin 1 Red
Faria Bus
Pin 2 White
Faria Bus
Pin 3 Green
Faria Bus
Pin 4 Black
Faria Bus
Pin 5 Not Used
Pin 6 Tan/Black Water Temp Sender
Pin 7 Tan
Air Temp Sender*
Pin 8 Not Used
Pin 9 Not Used
Pin 10 Not Used
Pin 11 Not Used
Pin 12 Not Used
Tan
Tan*
Tan/Black
Not Used
Not Used
Not Used
Not Used
Not Used
Not Used
RED + VOLTAGE (SPEED)
GRN SIGNAL (SPEED)
BARE GROUND (SPEED)
N/C WHT THERMISTER (TEMP)
N/C BRN THERMISTER (TEMP)
FARI
A
Water Temp Sender
White (Sender Signal)
Black & Shield (Ground)
FARI
A
* or as Paddlewheel Sender
or
