Page 30
MG2000 J1939 Tachometer
6
5
4
3
2
1
7
8
9
10
11
12
1
2
3
6
5
4
Harness HN0587
J1939 Tachometer
Cable
4- pin connector
12- pin connector
Pin A Red
Pin B White
Pin C Green
Pin D Black & Sheild
Pin 1 Red
Faria Bus
Pin 2 White
Faria Bus
Pin 3 Green
Faria Bus
Pin 4 Black
Faria Bus/Ground
Pin 5 Violet
Ignition(Wake)
Pin 6 Pink
Fuel Sender
Pin 7 Blu/Wht Trim Sender
Pin 8 Not Used
Pin 9 Not Used
Pin 10 Black
CAN GRND
Pin 11 Red
CAN H
Pin 12 White
CAN L
J1939 Cable
Pin C Black
Ground
Pin A Red
CAN H
Pin B White
CAN L
1 2 3 4 5 6 7 8 9 10 11 12
Heat
Shrink
Tubing
Heat
Shrink
Tubing
V
iolet
Black
Pin
k
Blue/wh
t
Not Used
Not Used
HN0587 r.A ecr 5668 11/05
A: CAN-H
C: CAN-Ground/Shield
B: CAN-L
+14 Vdc
Ground
Fuel
Sender
Trim
Sender
