Page 20
Software Id and Revision
1 Software Id
&
Revision
Minigateway
J1939
PGFxxxx
2
3
4
5
6
Available Functions for Display in J1939 MG2000 Tachometer
Screens
The functions listed below can be displayed in the user configurable screens. All of
the functions may not be available in your installation. If a function is selected for
display and that function does not appear on the screen, the function does not exist in
this installation. A function is selected for display by selecting it from within the editor
“Organize User Screens” list.
1. Volts
2. Coolant Temp
3. Engine Hours
4. Fuel Left
5. Fuel Used
6. Fuel Instant
7. Fuel Level (Bar Graph)
8. Transmission Pressure
9. Transmission Temp
10. Oil Pressure
11. Boost Pressure
12. Engine Load Percent
13. Throttle Position Percent
14. Transmission Gear
15. Trim (Bar Graph)
16. Water Pressure
