Page 26
MG2000 J1939 Tachometer PGN Table
Function PGN Bytes FMI
Engine Speed 61444 4,5
Engine Percent Load 61443 3
Accelerator Pedal Position 61443 2
Ground Referenced Speed 65265 2,3
Fuel Flow (GPH) 65266 1,2
Oil Pressure 65263 4
Boost Pressure 65270 2
Battery Potential 65271 5,6
Coolant Temperature 65262 1
Engine Hours 65253 1,2,3,4
Transmission Gear Position 61445 4
Transmission Oil Temperature 65272 4
Transmission Oil Pressure 65272 5,6
MG2000 J1939 Warnings Table
Warning PGN SPN FMI
EngineEmergencyStop 65226 Any N/A
CheckEngine 65226 Any engine flag N/A
LowOilPressure amber 65226 100 18
LowOilPressure red 65226 100 1
LowFuelPressure 65226 94 18
LowSystemVoltage 65226 167 18
HighSystemVoltage 65226 167 16
LowCoolantLevel 65226 111 18
HighBoostPressure 65226 102 2
RevLimitExceeded 65226 190 0
OverTemperature 65226 110 0
WaterInFuel 65226 97 15
WaterInFuel 65279 BYTE 1 N/A
