2680A/2686A
Getting Started Guide
34
Managing Your Network Using Fluke DAQ
The following procedures provide detailed instructions for using Fluke DAQ to:
•
Insert and configure 268XA devices, modules, channels, and computed
channels.
•
Start a scan
•
View scan data.
•
View alarms.
Inserting and Configuring a 268XA Device
To insert and configure a device
1.
Double-click the
icon on your desktop to start Fluke DAQ.
2.
Specify basic settings in the Fluke DAQ Application dialog.
