33
Connections for interlocking remote control
To control multiple display units by one remote control box, wire units as follows.
REMOTE
CONTROL
CONE Board
DISPLAY 1
CONE Board
DISPLAY 2
CONE Board
DISPLAY 3
CN-A13 CN-A14
CN-A13 CN-A14 CN-A13 CN-A14
Connect same pin numbers.
NH-10P
Connect same pin numbers.
NH-10P
Figure 4-37 Connections for interlocking remote control
