28
Fabrication, assembling 10P and 7P connectors
VINYL SHEATH
VINYL SHEATH
VINYL SHEATH
(OUTER)
SOLDER UNUSED CORES
AND EARTH WIRE TO
BRAIDED SHIELD
WIND VINYL TAPE CONNECTOR CASE
EARTH
WIRE CLAMP FIXING SCREW
CLAMP
SET
SCREW
2cm
BRAIDED
SHIELD
SOLDERING-SIDE
SOLDERING-SIDE
CLAMP SHIELDING TAPE
WITH CONNECTOR CLAMP
FOR GROUNDING.
WIND VINYL TAPE
CONNECTOR CASE
SOLDERING WIND SHIELDING TAPE
CLAMP FIXING SCREW
CLAMP
SET SCREW
VINYL SHEATH
(INNER)
VINYL SHEATH
(OUTER)
SOLDER UNUSED CORES
AND EARTH TO
BRAIDED SHIELD
EARTH WIRE
1cm
8cm
2cm
BRAIDED
SHIELD
ARMOR
3 mm
Figure 4-30 Fabrication of 10P, 7P connectors
