Component identification 71
Component identification
In this section
Components .......................................................................................................................................... 71
EID Location for the interface adapter ....................................................................................................... 71
Serial number location ............................................................................................................................ 72
Components
Item Description
1 Power
connector
2 Power
switch
3
Activity indicator light
4
Serial download connector
5 Keyboard
connector
6 Monitor
connector
7 Mouse
connector
8
RJ-45 Interface port (designated by the letter A)
9
Server connection ports
EID Location for the interface adapter
The EID for the interface adapter is a communication protocol between modular components of the
console switch system. The EID enables central management components, such as the console switch, to
