Step 1b - Networks and Communications — Optional
Description Device Type Part Number Maximum Quantity Tested & Supported
U=Tru64 UNIX
O=OpenVMS
L=Redhat V7.2 Linux
per system per hard partition: per system
ES47
Tower
Workstation
ES47 ES80 GS1280
Synchronous Communications Network Interface Cards
Dual-port Intelligent Synchronous
Communications NIC; requires one or
two BC3xx sync cables. PCI 3.3V,
32 b,
33 MHz
3X-PBXDD-AA 4/U
4/O 4:8/U
4:8/O
4:16/U
4:16/O 4:128/U
4:128/O
Quad-port Intelligent Synchronous
Communications NIC; requires one to
four BC3xx sync cables. PCI 3.3V,
32 b,
33 MHz
3X-PBXDD-AB 4/U
4/O 4:8/U
4:8/O
4:16/U
4:16/O 4:128/U
4:128/O
Asynchronous Communications Network Interface Cards
4-port Async Communications NIC with
DB-25 cable PCI 3.3V,
32 b,
33 MHz
PBXDA-BA 2/U
2/O 2:4/U
2:4/O
2:8/U
2:8/O
2:64/U
2:64/O
8-port Async Communications NIC PCI 3.3V,
32 b,
33 MHz
PBXDA-BB 2/U
2/O 2:4/U
2:4/O
2:8/U
2:8/O
2:64/U
2:64/O
16-port Async Communications
Controller and rackmount 16-port
distribution box with RJ45 connectors PCI 3.3V,
32 b,
33 MHz
PBXDA-AC 2/U
2/O 2:4/U
2:4/O
2:8/U
2:8/O
2:64/U
2:64/O
Cables for Ethernet,
ATM, Synchronous,
and Asynchronous
Network Interface
Cards Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-SC
connectors. xx = 2E, 4E, 01, 03, 10, 20, 30 for 2.4, 4.5, 1, 3, 10, 20, and 30
meters BN34B-xx
Category 5e (4-Unshielded Twisted Pairs / UTP) straight-through cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity. xx
= 0B, 0E, 01, 03, 04, 07 for 0.2, 0.5, 1, 3, 4, and 7 meters BN25G-xx
Category 5e (4-Twisted Pairs, Screened/ ScTP) straight-through cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub connectivity. xx
= 0B, 0E, 01, 03, 04, 07 for 0.2, 0.5, 1, 3, 4, and 7 meters BN26M-xx
Category 5e (4-Unshielded Twisted Pairs / UTP) Xover cable with RJ45-to-RJ45
connectors for system to switch, repeater, or hub connectivity. xx = 0E, 01, 03,
04, 07 for 0.5, 1, 3, 4, and 7 meters BN24Q-xx
Category 5e (4-Twisted Pairs, Screened / ScTP) Xover cable with RJ45-to-RJ45
connectors for system to switch, repeater, or hub connectivity. xx = 0E, 01, 03,
04, 07 for 0.5, 1, 3, 4, and 7 meters BN28Q-xx
EIA-530 Single-port synchronous cable 3X-BC34G-06
V.24/EIA-232 Single-port synchronous cable 3X-BC34L-06
V.11/x.21 Single-port synchronous cable 3X-BC33S-06
V.35 Single-port synchronous cable 3X-BC34T-06
RJ45-to-DB-25 Asynchronous Converter Cable CXI01-AC
QuickSpecs
HP AlphaServer GS1280 Systems
ES/GS Common Options
DA - 11921 Worldwide — Version 24 — July 23, 2007 Page 31
