Total I/O Drawer Connections
=12 I/O connections used
I/O Module
for
Connection
to CPU in a
System
Building
Block
Drawer
I/O Buses
I/O Slots
Dual
Redundant
Power
Supplies
USB/
Ultra3
SCSI
Adapter
Card
DVD/
CD-RW
Drive
Universal
Slot for
Disks
Part Number
Standard I/O
Drawer,
Expansion
1
3 PCI-X
1 AGP 4X
8 PCI-X
1 PCI 3.3V;
2 PCI, 5V
1 AGP 4X
Yes
No
No
None
3X-BA70A-BA
Standard I/O
Drawer, Master
1
3 PCI-X
1 AGP 4X
8 PCI-X
1 PCI 3.3V;
2 PCI, 5V
1 AGP 4X
Yes
1 in PCI
3.3V Slot
1
2
4
3X-BA70A-AA
High
Performance
I/O Drawer,
Expansion
1 standard
3 additional,
optional
1
2 to 8
PCI-X
2 to 8
PCI-X
Yes
No
No
None
3X-BA70B-BA
High
Performance
I/O Drawer,
Master
1 standard
3 additional,
optional
1
2 to 8
PCI-X
2 to 8
PCI-X
Yes
1 in PCI-X
Slot
1
2
4
3X-BA70B-AA
Add-in I/O Module for High Performance I/O Drawers. Each module supports two PCI-X slots. Up to three
modules may be added to the base High Performance I/O Drawer.
3X-KFMHA-AA
I/O 3.3-meter cable for connection between GS1280 System Building Block Drawer and I/O Building Block
Drawers mounted in a system rack or adjacent expansion rack; select one cable for each I/O drawer
ordered and one cable per Add-in I/O Module (3X-KFMHA-AA) if ordered.
3X-BNPSA-04
I/O 4.5-meter cable for connection spanning one or two racks between GS1280 System Building Block
Drawer and I/O Building Block Drawer mounted in an expansion rack; select one cable for each I/O drawer
ordered and one cable per Add-in I/O Module (3X-KFMHA-AA) if ordered.
3X-BNPSA-05
I/O 6.0-meter cable for connection spanning three racks between GS1280 System Building Block Drawer
and I/O Building Block Drawer mounted in an expansion rack; select one cable for each I/O drawer
ordered and one cable per Add-in I/O Module (3X-KFMHA-AA) if ordered.
3X-BNPSA-06
