Technical specifications, Quickspecs – HP ProLiant DL360 User Manual
Page 46
System Unit
Dimensions (H x W x D) 1.70 x 16.78 x 27.75 in (4.32 x 42.62 x 70.49 cm)
Weight
Maximum (six hard drives
installed, two power
supply, two processor)
37 lb (16.78 kg)
No hard drives installed,
one power supply, one
processor
27.5 lb (12.47 kg)
Input Requirements
Rated Input Voltage
100 to 240 VAC
Rated Input Current
7.1 Amps (at 120VAC) to 3.5 Amps (240 at
VAC)
Rated Input Frequency
50 to 60 Hz
Rated Input Power
852 W
BTU Rating
2910 BTU/HR (at 120 VAC); 2870 (at 240 VAC)
NOTE: The BTU rating listed is for the Rated Input Power of 852 W.
Power Specifications
To review typical system power ratings use the Power Calculator which is
available via the online tool located at URL:
To drill down to calculators:
- Click on: "ProLiant Servers"
- Click on the Server of interest. Example: DL360 G5
- Click on: "Power Calculator" link. (You may need to scroll down to see it)
Power Supply Output
Power
(per power supply)
Rated Steady-State Power 700 W
Temperature Range
Operating
50° to 95°F (10° to 35°C) at sea level with an
altitude derating of 1.0°C per every 1000 ft
(300 m) above sea level to a maximum of
10,000 ft (3000 m), no direct sustained sunlight.
Maximum rate of change is 10°C/Hr.
Storage
-40° to 158°F (-40° to 70°C) – Maximum rate of
change is 20°C/Hr.
Relative Humidity
(non-condensing)
Operating
10 to 90% relative humidity (Rh), 82.4°F (28°C)
maximum wet bulb temperature
Storage
5 to 95% relative humidity (Rh), based upon a
maximum temperature of 113° F (45° C). Altitude
maximum for storage corresponds to a pressure
minimum of 70 KPa.
Maximum Wet Bulb
Temperature
82.4°F (28°C)
Acoustic Noise
Listed are the declared A-Weighted sound power levels (LWAd) and
declared average bystander position A-Weighted sound pressure levels
(LpAm) when the product is operating in a 73.4°F (23°C) ambient
QuickSpecs
HP ProLiant DL360 Generation 5
Technical Specifications
DA - 12476 Worldwide QuickSpecs — Version 16 — 1/16/2007
Page 46
