NOTE: Memory configurations listed do not apply to "Factory Integrated Models".
NOTE: Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at 667 MHz and in systems with a
FSB running at 1066 MHz or 667 MHz the memory DIMMs will run at 533 MHz.

HP ProLiant DL360 G5 Entry and Base Models

Standard Memory
1 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) installed (2 x 512 MB)

Upgrading Memory and Memory Interleaving
When upgrading memory, DIMMs 1A and 2A must match. DIMMs 3B and 4B, DIMMs 5C and 6C, and DIMMs 7D and 8D must
match and must be installed as a pair. When DIMMs 1A and 2A are populated the system is automatically configured for 2:1
interleaving. When all 4 banks are populated the system is automatically configured for 4:1 interleaving. When four, six, or eight
DIMMs are populated with identical DIMMs the system is automatically configured for bank interleaving.

Standard Memory Plus Optional Memory
Up to 25 GB memory is available with the standard memory of 1 GB and the optional installation of PC2-5300 Fully Buffered
DIMMs (DDR2-667) memory kits.

Standard Memory Replaced with Optional Memory
Up to 32 GB of memory is available with the removal of the standard 512 MB of memory and the optional installation of PC2-5300
Fully Buffered DIMMs (DDR2-667) memory kits.

NOTE: 4 GB Fully Buffered DIMMs kits will be available shortly following server availability to allow a maximum of 32 GB. Today's
maximum is 16 GB utilizing 2 GB DIMMs.

NOTE: Chart does not represent all possible configurations.

Memory

Slot

Standard

1 GB

512 MB

Empty

Optional

25 GB

512 MB

4 GB

Maximum

32 GB

4 GB

NOTE: In the online spare configuration, the ROM automatically configures the last populated bank as the spare memory. If only
banks A and B are populated, bank B is the spare bank. If banks A, B, and C are populated, bank C is the spare bank, If banks A,
B, C and D are populated, bank D is the spare bank, Online spare memory is configured through RBSU.
NOTE: Mirrored Memory uses mirrored banks to provide a high level of memory redundancy. Customer chooses to implement or not:
User selectable via BIOS and default is off.

Following are memory options available from HP:

1 GB FBD PC2-5300 2 x 512 MB Kit

397409-B21

2 GB FBD PC2-5300 2 x 1 GB Kit

397411-B21

4 GB FBD PC2-5300 2 x 2 GB Kit

397413-B21

8 GB FBD PC2-5300 2 x 4 GB Kit

397415-B21
