Configuration Branch 0
Bank A
1A and 3A
Branch 0
Bank C
2C and 4C
Branch 1
Bank B
5B and 7B
Branch 1
Bank D
6D and 8D
1 * X - - -
2 X X - -
3 X X X X
*NOTE: Configuration 1 is only supported if using bank A, populated with dual-rank FBDIMMs.
Mirrored memory FBDIMMs configuration requirements (in addition to general configuration requirements):
Banks A and B must be fully populated.
Bank A and bank B must contain FBDIMMs with identical part numbers. If installed, bank C and bank D must also contain
FBDIMMs with identical part numbers.
When using mirrored memory mode, FBDIMMs must be populated as specified in the following table:
Configuration Bank A
1A and 3A
Bank B
5B and 7B
Bank C
2C and 4C
Bank D
6D and 8D
1 X X - -
2 X X X X
QuickSpecs
HP ProLiant DL360 Generation 5
Memory
DA - 12476 Worldwide QuickSpecs — Version 16 — 1/16/2007 Page 39
