Fisher & Paykel Series 9 Professional Series 30 Inch Double Convection Smart Electric Wall Oven Installation Guide - Manual (Page 11)

11
SECURE THE OVEN TO THE CABINETRY
IMPORTANT!
z
Do not lift the oven by the door handle.
z
Do not over-tighten the screws.
z
Do not seal the oven into the cabinetry with silicone or glue.
This makes future servicing difficult. Fisher & Paykel will not
cover the costs of removing the oven, or of damage caused
by this removal.
1 Position the oven in the prepared cavity.
2 Open the oven door fully.
3 Mark and pre-drill the screw holes.
4 Use the supplied screws to secure the oven to the cabinetry.
Ensure supplied spacer is fitted between oven and cabinetry.
Spacer
