wolfappliance.com | 9
WOLF LOGO
To attach the Wolf logo, clean the mounting area with
rubbing alcohol. Remove the paper backing, position the
logo parallel with the bottom of the hood, and press into
place.
INSTALLATION
Complete the Installation
FILTERS
Install the grease cups at the bottom rear edge of the hood.
Orient the filters with lines running vertically. To install, place
the top edge of the filter against the spring, press upward
then rotate the bottom toward the back of the hood. Refer
to the illustration below.
LIGHT BULBS
A suction-cup-style light bulb changer is provided with
the hood. To install, use the changer to push the bulb into
the receptacle and rotate counterclockwise one-quarter
turn. Refer to the illustration below.
SIDE VIEW
SPRING
FILTER
GREASE
CUP
LIGHT BULB
CHANGER
Filters
Light bulb installation
