4 | Wolf Customer Care 800.222.7820
Installation Requirements
Install the hood 36" (914) to 42" (1067) from the bottom of
the hood to the countertop.
BLOWER ASSEMBLIES
Outdoor Wall Hoods require an internal, in-line, or remote
blower assembly, avail able through an authorized Wolf
dealer. For local dealer information, visit the find a show-
room section of our website, wolfappliance.com. Refer to
specific installation instructions provided with each blower
assembly.
DUCT COVER
Optional stainless steel duct covers, in multiple heights, are
available through your authorized Wolf dealer. Duct covers
must be attached to the hood prior to hood installation. For
local dealer information, visit the find a showroom section of
our website, wolfappliance.com.
SPECIFICATIONS
Ducting
WARNING
To reduce the risk of fire, use only metal ducting.
IMPORTANT NOTE: Consult a qualified HVAC professional
for specific installation and ducting applications.
Outdoor Wall Hoods accommodate a 10" (254) round duct.
Use only rigid metal ducting.
A straight, short duct run will allow the hood to perform
most efficiently. If the duct run exceeds 50'
(15 m) , a higher
CFM blower may be required to maintain proper air flow.
Internal and in-line blowers require a roof or wall cap.
Connect ducting to the cap or to the remote blower and
work back towards the hood. Use sheet metal screws and
high-temperature duct tape to seal joints between ducting
sections.
Outdoor Wall Hoods include a backdraft damper. Local
codes may require the use of an additional backdraft and/or
make-up air damper. Contact your local HVAC professional
for specific requirements.
A make-up air damper is available through an authorized
Wolf dealer. For local dealer information, visit the find a
showroom section of our website, wolfappliance.com.
