Encoder with Profibus interface
23
10.4.2 Preset value
The preset value is set according to the procedure described in chapter 9�3�2� Only
difference: Setting of the preset value with the manufacturer-specific classes ifm
2�1 and ifm 2�2 is confirmed via a status bit�
Status bits Data bits
Bit 31 30 29 28 27 26 25 24���0
Master
→ encoder
1 0 0 0 0 0 0 Tranfer of the requested value
(= preset value)
Encoder
→ master
1 0 0 0 0 0 1 New = requested process actual value is
transferred
Master
→ encoder
0 0 0 0 0 0 0 Reset bit 31 - normal mode
Encoder
→ master
0 0 0 0 0 0 1 New = requested process actual value is
transferred
