22
Speed
When Manual is selected within the Stitch Mode
the motor speed can be increased or decreased
by pressing the Speed “+” or “-” buttons. To
increase the Manual Mode motor speed press
the Speed “+” button. To decrease speed press
the Speed “-” button. This has the same effect as
pressing the “+” or “-” buttons on the machine’s
handles. The speed range is between 3% and
100%, or between 100 and 1800 stitches per min-
ute (SPM). The percent speed is displayed in the
white box located at the top right side of screen.
Stitches per minute (SPM) is not displayed
within the machine’s software. (Figure 20)
Manual Presets
Save up to three manual-mode preset speeds to
quickly switch between speed preferences. For
example, you may prefer a slower speed when us-
ing rulers and a faster speed when doing all-over
meandering quilting. Use the “+” and “-“ buttons
to adjust the speed percentage and then press
one of the record buttons next to the preset value
to store that speed as a preset. When you want
to use one of the preset speeds, simply press the
speed. (Figure 21)
On/Off Indicator
The box in the center of the top bar turns green
when you press the “Start” button on the handles
to indicate the needle is in motion. When you
press “Stop,” the box will turn red. (Figure 22)
Regulated Mode Screen Button Functions
Stitches Per Inch (SPI)
Pressing the “+” or “-” buttons near the top right
portion of the screen will increase or decrease
the stitches per inch (SPI) setting. The setting
is reflected in the white indicator box at the top
right portion of the screen. This value can be
adjusted between 4 and 18 stitches per inch.
(Figure 23)
Stitch Mode
More
Up
Down
Needle Stop
Manual 58 %
Regulated
Speed
Presets
Manual
30%
50%
70%
Stitch Mode
More
Up
Down
Needle Stop
Manual 94 %
Regulated
Speed
Presets
Manual
30%
50%
70%
Stitch Mode
More
Up
Down
Needle Stop
Manual 58 %
Regulated
Speed
Presets
Manual
30%
50%
70%
Figure 20
Figure 22
Figure 21
Stitch Mode
More
Up
Down
Needle Stop
Regulated 11 SPI
Regulated
SPI
SR Style
Manual
Precision
Cruise
Figure 23
