13
Installing the
Power Cord
NOTE: Please make sure that the machine is
in the “O” or off position before plugging
into power source.
Insert the cord into the top power connector on
the rear of the machine (Figure 9). Plug the three-
prong end into power source.
The lower power connector is for powering other
attachments. (For future development)
Figure 9
Power
Eyelets
Figure 10
Installing the
Thread Mast
Locate the threaded hole on top of the machine
near the rear by the handwheel. The thread mast
comes with the washer and nut on it. Remove the
nut and washer, replace the nut onto the mast and
then place the washer under the nut and onto the
machine painted surface. The washer protects the
painted surface when the nut is tightened. Tighten
the mast clockwise until it is securely in place. Use
the nut to secure the mast to the machine.
NOTE: The eyelets of the thread mast must
be centered over the spool pins—so the cone
will not pull, turn or tilt, causing thread
tension problems (Figure 10).
