Lingenfelter L300080607 Lingenfelter Suburban Yukon Aux Fan Kit AC Clutch Control 2005-07 vE User Manual
Page 20
Page
Quantity DESCRIPTION
Part #
1
Passenger side fan bracket, CK truck fan system
L960150607
1
Driver side fan bracket, CK truck fan system
L960160607
1
2007-2010 2500 Suburban & Yukon XL aux fan harness, AC control
L480110607
1
Spal 225 mm fan with WeatherPak connector
30100381li
1
Spal 255 mm fan with WeatherPak connector
30100374li
2
Fan mounting tab
30130032
1
6 gang fuse panel, 65 amp capacity
73897
2
3/8" high temperature loom, 22 inches
1764
2
15 amp buss fuse (blue)
782-2184
1
6 gang fuse panel decal, white
L920050000
2
M4.2x1.41x20mm Phillips washer head self tapping screw
12060
2
Aluminum round spacer 5/8" OD, 1/4" Length, 1/4" Screw Size
92511A087
2
M6.3-1.81 x 20mm self tapping screw
AV12351
2
M6.3-1.81 x 30mm self tapping screw
AV12354
2
1/4-20 Spin Lock nut
34292
1
M8X1.25 flange nut
90701
6
Zip tie, 7.5", black
1
16-14 AWG heat shrink tube
1
In-line crimp connector, sealed, 16-14 awg (clear w blue)
DC-940010
2
Push fastener
AV12567
1
Installation instructions
1
Lingenfelter decal
L920010000
Lingenfelter Performance Engineering
1557 Winchester Road
Decatur, IN 46733
(260) 724-2552
(260) 724-0422 fax
www.lingenfelter.com
L300080607 LPE Auxiliary Fan Kit With AC Clutch Control Installation Manual - Rev E.indd
Parts List
