Imaxrc B606-AC-PRO - Manual (Page 5)

Exterior and accessories
Key features:
: mode selection/stop/back button. Press this key to select in the main menu or back to the main menu and to stop
during the process.
:
reduce and increase button, you can browse other concerning information by this button during the charge/discharge
process. When you are setting parameters, press key for reduce, and key for increase.
: select/enter button, to start work by press it more than 2 seconds.
Performance parameter
Input voltage range DC:11~18V
AC:100~240V
Charge current range 0.1~6.0A
Discharge current range 0.1~2.0A
Charge power limited max.80W
Discharge power limited max.10W
Balance current max.300mA
Balance tolerance 0.01V
Nicd/NiMH battery cell count 1~18cells
Lithium battery types Li-po,Li-ion,Li-Fe
Lithium battery cell count 1~6series
Pb battery voltage 2-24V
Weight: 640g
Dimensions: 145x145x56mm
Mode
Esc
Dec./Inc.
Dec. Inc.
Enter
start

    
   
 
    
    
    
  
   
  
  
 
  
 
  
  
