www.austin-hughes.com UM-IPM-02-Q414V3 P.42
4. How to move out a PDU (without a replacement) ?
Step 1 - Prepare an appropriate length Cat. 5/6 cable.
Step 2 - Click Disable Monitoring in
Step 3
- Use the Cat. 5/6 cable to bridge over the removed PDU to minimize log/data loss.
Step 4
- Power off & unplug the device(s) which connected to the PDU.
Step 5
- Power off & remove the PDU from connection.
Step 6
- Enable alarm email in page.
If the removed PDU NOT in the last level, you MUST reconfi gure and reset the level for
the affected PDU(s) which next to the removed PDU.
Ignore step 1 & 3 if the removed PDU is in the last level.
5. How to add an extra PDU to an existing PDU group ?
Step 1
- Prepare a PDU and set the PDU level accordingly.
(Please refer to < 1.2 > display 9.1 for the PDU level setting )
Step 2 - Prepare an appropriate length Cat. 5/6 cable.
Step 3 - Click Set maintenance in
added PDU.
Step 4
- Install and connect the new PDU.
Step 5
- Power on the new PDU.
Step 6
- Reconfi gure & reset the level for the affected PDU(s) which next to the added PDU.
Step 7 - Click Remove maintenance in
Step 8 - Click Search in page to search the new installed PDU.
Step 9 - Confi gure the new PDU in
Alarm Amp
, Name, Location…
Step 10
- Enable alarm email in page.
Ignore step 3, 6 & 7 if the added PDU is in the last level
