V676
®
CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
19
TECHNICAL SPECIFICATIONS
V676 Control Console
* These features are available with the optional DMX Processing Module. Refer to
Console Function Capacities:
+
Channels: 4,000 multiple parameter luminaires
+
Color Palettes: 1,000
+
Beam Palettes: 1,000
+
Presets: 1,000
+
Macros: 2,000
+
Effects: 1,000
+
Sets: 1,000
+
Sequences: 1,000
+
Dynamics: 500
+
System Snapshots: 1,000
+
Cue Snapshots: 10,000
+
Cues: 10,000
+
Stacks: 1,000
+
Submasters: 30
External Equipment:
+
Up to 2 external monitor displays
+
Channel Select Panel for fast and intuitive access to
2,000 luminaires
+
PRG Node Plus - provides up to 6 additional
universes
+
PRG Super Node™ - provides up to 16 additional
universes
+
PRG Series 400 Ethernet Switch - allows 2 or more
consoles to be linked together
Outputs:
+
Fiber Optic: 1 - 702 universes possible
+
Ethernet: 1 - 702 universes possible
+
Art-Net/sACN: 16 universes *
+
DMX512: 8 Universes *
Interfaces:
+
Copper and Fiber Optic Ethernet connections for
communications protocol
+
(8) 5-pin DMX512 Outputs *
+
(1) 5-pin DMX512 Input *
+
(1) Ethernet DMX Output *
+
(2) Mac USB Ports
+
(1) Auxiliary Mac Ethernet
+
(2) DVI-D Single Link
+
(3) Integrated Display Outputs
+
(2) IEC Convenience Outlets
+
SMPTE Time Code input
+
MIDI Time Code input
+
MIDI Show Control input and output
+
MIDI Notes input
+
External Trigger
Electrical Specifications:
+
AC Power Input via Latching IEC-320 Inlet
+
Line Cord Provided with Edison Plug
+
Universal Voltage Range: 100-240 VAC, 50/60 Hz, 10A Max
+
Maximum Ambient Temperature: T
A
= 50° C
+
Power Consumption: Console (with displays) - Less than
600 watts
Physical Specifications:
+
CPU: Dual Apple® Mac Mini® Quad-Core Intel Core i7
2.6GHz
+
Displays:
-
5 integrated, full-color touchscreen displays.
-
Up to 2 external, full-color touchscreens,
or
Up to 2 external DVI monitors
+
External Channel Select Panel: 10,000 channels
+
Weight and Dimensions:
-
120 lbs. (54.43 kg) with accessories
-
46.8" (118.9 cm) W x 11.6" (29.5 cm) H x
28.6" (72.6 cm) D (including mounting brackets)
