V676
®
CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
Text Conventions and Icons
The following button styles are used throughout this manual:
Note these equivalent buttons on the Mac keyboard and front panel command-line keypad:
[Button]
Front panel "hard" button.
Example: Press [Cue] [1] [Enter] to recall Cue 1.
Optional desk button press.
Example: Press [Store]
[Button 1 ] / [Button 2]
Front Panel button combination sequence.
Press and hold Button 1 while pressing Button 2.
[Button/Button]
Front Panel button double-click.
Button
Touchscreen "soft" button.
Example: Press
Plan View
to open plan view.
Button
Software menu or window dialog button.
Example: Click
OK
.
Example: At
