V676
®
CONTROL CONSOLE INSTALLATION & OPERATION MANUAL
3
PRODUCT OVERVIEW
Features
The V676 console is a lighting control desk capable of operating automated luminaires, conventional fixtures and
media servers. The console supports up to 702 universes when used with PRG Node Plus units.
Console Function Capacities:
+
Channels: 4,000 multiple parameter luminaires
+
Color Palettes: 1,000
+
Beam Palettes: 1,000
+
Presets: 1,000
+
Macros: 2,000
+
Effects: 1,000
+
Sets: 1,000
+
Sequences: 1,000
+
Dynamics: 500
+
System Snapshots: 1,000
+
Cue Snapshots: 10,000
+
Cues: 10,000
+
Stacks: 1,000
+
Submasters: 30
External Equipment:
+
Up to 2 external monitor displays
+
Channel Select Panel for fast and intuitive access to 2,000 luminaires
+
PRG Node Plus - provides up to 6 additional universes
+
PRG Super Node™ - provides up to 16 additional universes
+
PRG Series 400 Ethernet Switch - allows 2 or more consoles to be linked together
Outputs:
+
Fiber Optic: 1 - 702 universes possible
+
Ethernet: 1 - 702 universes possible
+
Art-Net/sACN: 16 universes *
+
DMX512: 8 universes *
Interfaces:
* These features are available with the optional DMX Processing Module. Refer to
+
Copper and Fiber Optic Ethernet connections
for communications protocol
+
(8) 5-pin DMX512 Outputs *
+
(1) 5-pin DMX512 Input *
+
(1) Ethernet DMX Output *
+
(2) Mac USB Ports
+
(1) Auxiliary Mac Ethernet
+
(2) DVI-D Single Link
+
(3) Integrated Display Outputs
+
(2) IEC Convenience Outlets
+
SMPTE Time Code input
+
MIDI Time Code input
+
MIDI Show Control input and output
+
MIDI Notes input
+
External Trigger
