4 Installation
4.1 Transport
Reach under the edge of the housing to carry the device.
CAUTION!
The channel must not be used for lifting.
4.2 Unpacking
The Vibratory feeder is packed either in a cardboard or wooden box.
n Carefully open the cardboard box with a knife (do not cut too deep,
since otherwise the contents could become damaged) and remove
the packaging material.
n It is best to open the wooden box by pulling out the metal clips with
pliers.
n Carefully lift out the Vibratory feeder.
n Check the Vibratory feeder for possible damage in transit.
n Compare the contents of the delivery with your order.
4.3 Set-up
The Vibratory feeder must be placed in a horizontal position on a level
surface or stable stand.
Its rubber feet provide stability (it is not necessary to attach it to your
work place), however it should be easy to access and there should be
sufficient space.
The control housing can be set up or hung up. Holes are provided on the
inside of its underside for the wall mounting option.
CAUTION!
The surface must be stable and not resonate.
