3 Technical data
3.1 Dimensions
340 x 440 x 140 mm (height x width x depth)
Required space of 340 x 440 mm
No safety distances necessary
3.2 Weight
12 kg (net), 16 kg (gross)
3.3 Voltage
The device can be operated within two different voltage ranges (auto-
matic adjustment):
Single-phase AC voltage of 100-120 V with protective conductor, 50/60
Hz
Single-phase AC voltage of 200-240 V with protective conductor, 50/60
Hz
3.4 Electrical fuses
The control box contains a safety fuse which disconnects the device
(single phase) from the mains supply in the event of a malfunction to
prevent any consequent damage.
Equivalent: T1.25A micro fuse (5 x 20 mm)
3.5 Power consumption
20 watts
3.6 Vibration frequency
3000 to 4800 vibrations/min. depending on the intensity set.
The vibration frequency rises if a low vibration intensity is set and is at a
minimum at natural frequency.
