PeciFicAtioNs
Specifications
A-Net I/O - MH10 10x EtherCon RJ45 connectors
A-Net I/O - MH10f 8x EtherCon RJ45 connectors; 2x SFP fiber
optic ports (modules not supplied)
MH10f SFP Module 100 Mbps Fast Ethernet; Class 1 laser device
SFP: use duplex LC connector
Hot‑pluggable
Fiber Optic Modes Multi‑Mode, up to 2km;
Single‑Mode, up to 50km;
Fiber optic performance varies by transceiver
Network Sample Rates 44.1/48kHz; 88.2/96kHz; 176.4/192kHz
Network Sample Rate
Range
1x 44.1/48kHz, 39.7kHz to 52kHz
2x 88.2/96kHz, 79.4kHz to 104kHz
4x 176.4/192kHz, 158.8kHz to 208kHz
Network Bit Depth 24‑bit, uncompressed
Network Latency <420µs
Cable Length, Cat-5e Maximum 400 feet (120 meters);
Use Unshielded Twisted Pair (UTP) cable
Power Supply MH10 100‑240VAC 50‑60Hz, 15W
Internal switching power supply;
IEC connector, interchangeable; no DC
backup power
Power Supply MH10f 100‑240VAC 50‑60Hz, 24W
Internal switching power supply;
IEC connector, interchangeable
MH10f Backup DC Power 24VDC, ±5%; 4‑pin XLR, external supply
Pin 1: Ground; Pin 4: 24VDC;
Pin 2, 3: no connect
Input Power Required: 24VDC ±5%, 0.8 amp
typical, 1.3 amp max.
DC Jack: Neutrik NC4MAH
DC Jack Mating Connector: Neutrik NC4FX or
NC4FXX
Fuse 250V, F4AL
Dimensions 1U; 19”w x 8”d x 1.75”h
482.6 x 203 x 45 mm
Weight 8 pounds;
3.63 kg
All Aviom products are designed and manufactured in the USA.
