D800-Dante Specifications
Dante Primary I/O Locking RJ45 connector
Dante Secondary I/O Locking RJ45 connector
Stereo Link
Four DIP Switch blocks: 1-16, 17-32, 33-48, and 49-64;
used to set up to 32 channel pairs as stereo links
Stereo Link Defeat Bypasses DIP switch stereo link settings
Disable DIP switch
Chooses Dante (down) or A-Net In (up) as the input source for
the D800-Dante;
When Dante is enabled, audio from the Network Mix Back
feature is available to the Dante network.
ID1, ID2 DIP Switch Reserved
A, B, C, D DIP switch Reserved
LEDs (rear panel)
Error (red);
Sync (green);
1GB Active (red);
Network Activity (green)
